| Video |
| Imaging Device |
1/2.8″ 2MP CMOS |
| Resolution |
1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate |
H.265/H.264: Max. 60fps at all resolutions
Motion JPEG: Max. 30fps |
| Min. Illumination |
Color: 0.1Lux(F1.6, 1/30sec)
BW: 0Lux(IR LED on) |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation
USB: Micro USB Type B, 1280×720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.2~10mm(3.1x) motorized varifocal |
| Max. Aperture Ratio |
F1.6(Wide) ~ F2.9(Tele) |
| Angular Field of View |
H: 109.0°(Wide) ~ 33.2°(Tele) / V: 57.4°(Wide) ~ 18.7°(Tele) / D: 132.0°(Wide) ~ 38.0°(Tele) |
| Min. Object Distance |
0.5m(1.64ft) |
| Focus Control |
Simple Focus |
| Lens Type |
DC auto iris |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ |
| Digital Image Stabilization |
Support |
| Defog |
Support |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, polygonal zones
– Color: Grey/Green/Red/Blue/Black/White
– Mosaic |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
| Analytics |
Defocus detection, Directional detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line |
| Alarm Triggers |
Analytics, Network disconnect |
| Alarm events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Handover |
| IR Viewable Length |
30m(98.42ft) |
| Network |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 5 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SRTP |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| General |
| Web Viewer |
Supported OS: Windows 8.1, 10, Mac OS X 10.13
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Memory |
1024MB RAM, 256MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP66, IK10, NEMA4X |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
Max 11W, typical 5W |
| Mechanical |
| Color / Material |
Dark grey / Aluminum |
| Product Dimensions / Weight |
Ø91×322.9mm(Ø3.58”x12.71”), 1,298g(2.86lb) |
| Compatible Conduit hole / Gangbox |
3/4″ |
| Backbox |
SBO-126B |
