| Video |
| Imaging Device |
1/2″ CMOS |
| Resolution |
1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360 |
| Max. Framerate |
H.265/H.264: Max. 60/50fps(60Hz/50Hz, AI analytics on), Max. 120/100fps(60Hz/50Hz, AI analytics off)
MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
| Min. Illumination |
Color: 0.006Lux(F1.2, 1/30sec,30IRE) B/W : 0.0006Lux(F1.2, 1/30sec,30IRE), 30/25fps
Color: 0.012Lux(F1.2, 1/60sec,30IRE) B/W : 0.0012Lux(F1.2, 1/60sec,30IRE), 60/50fps
Color: 0.024Lux(F1.2, 1/120sec,30IRE) B/W : 0.0024Lux(F1.2, 1/120sec,30IRE), 120/100fps |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720×480(N), 720×576(P) for installation
USB: Micro USB Type B, 1280×720 for installation |
| Lens |
| Focus Control |
Simple focus |
| Lens Type |
DC auto iris, P iris, Manual, I-CS |
| Mount Type |
C mount, CS mount |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNR, WiseNR Ⅱ(using AI engine) |
| Digital Image Stabilization |
Stabilization Support(built-in gyro sensor) |
| Motion Detection |
8ea, polygonal zones |
| Privacy Masking |
6ea, rectangle zones
– Color: Gray/Green/Red/Blue/Black/White |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Auto prefer shutter control based on AI engine |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Classified object type : Person/Face/Vehicle/License plate
Attributes : Person(Gender, Color and Bag), Face(Age, Gender, Mask and Glasses), Vehicle(Type:car/bus/truck/motorcycle/bicycle and Color)
Support Bestshot per object
Analytics events based on AI engine
– Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit), Face mask detection, Digital auto tracking, Social distancing detection
Analytics events
– Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear)*Some of the video analytics only works with people and vehicle detection |
| Business Intelligence |
People counting, Queue management, Heatmap based on AI engine |
| Serial Interface |
RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) |
| Alarm I/O |
2 configurable I/O ports, DC 12V output(Max. 50mA) |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Handover
Audio playback |
| Audio In |
Selectable(mic in/line in/Built in mic)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100/1000 BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(using AI engine) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast
Multiple streaming(Up to 5 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Device Certificate(Hanwha Techwin Root CA)
TPM with FIPS 140-2 level2
Secure boot, Verify firmware forgery |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| General |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 2slots 512GB |
| Memory |
4096MB RAM, 512MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Input Voltage |
PoE+(IEEE802.3at), 12VDC |
| Power Consumption |
PoE+: Max 17.5W, Typ 13.7W
12VDC: Max 14W, Typ 10.6W |
| Mechanical |
| Color / Material |
Body: Black / Aluminum |
| Product Dimensions / Weight |
81x67x165mm(3.19×2.64×6.48″), Weight : 0.88kg(1.94lb) |
