| Video |
| Imaging Device |
1/1.8″ 6MP CMOS |
| Resolution |
2560×1920, 2560×1440, 1920×1080, 1600×1200, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
| Min. Illumination |
Color: 0.07Lux(F1.2, 1/30sec)
BW: 0.007Lux (F1.2, 1/30sec) |
| Video Out |
USB: Micro USB type B, 1280×720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.6~9.4mm(2.6x) motorized varifocal |
| Max. Aperture Ratio |
F1.2(Wide) ~ F2.4(Tele) |
| Angular Field of View |
H: 102.5°(Wide)~38.7°(Tele)
V: 74.2°(Wide)~29.0°(Tele)
D: 135.5°(Wide)~48.6°(Tele) |
| Min. Object Distance |
0.5m(1.64ft) |
| Focus Control |
Simple focus, Manual |
| Lens Type |
DC auto iris, P iris(IR corrected) |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
Remote adjustment (Max. 200cycles)
±175˚ / 0~85˚ / ±175˚ |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ |
| Digital Image Stabilization |
Support |
| Defog |
Support |
| Motion Detection |
8ea, 8point Polygonal zones |
| Privacy Masking |
32ea, 4point Quadrangle zones
– Color : Gray, Green, Red, Blue, Black, White
– Mosaic |
| Gain Control |
Support |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification, Shock detection |
| Business Intelligence |
People counting, Queue management, Heatmap |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm events |
When alarm trigger occurred
– File upload(image) : e-mail/FTP
– Notification : e-mail
– Recording : SD/SDHC/SDXC or NAS recording at event triggers
– Alarm output
– Handover
– Audio clip playback |
| Audio In |
Selectable(mic in/line in/built-in mic)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| Network |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access Log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian |
| Edge Storage |
Micro SD/SDHC/SDXC 2slot 512GB |
| Memory |
1024MB RAM, 256MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-25°C ~ +60°C (-13°F ~ +140°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP52, IK10 |
| Input Voltage |
PoE(IEEE802.3af, Class3), 12VDC |
| Power Consumption |
PoE: Max 11W, typical 5.40W
12VDC: Max 9W, typical 3.75W |
| Mechanical |
| Color / Material |
White / Aluminum |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
Ø160x125mm(Ø6.3×4.9″) / 1.45kg(3.2lb) |
