| Video |
| Imaging Device |
1/2.8″ 2MP CMOS |
| Resolution |
1920×1080, 1280×1024, 1280×960, 1280×720,
1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate |
H.265/H.264: Max.60fps/50fps(60Hz/50Hz)
MJPEG: Max.30fps/25fps(60Hz/50Hz) |
| Min. Illumination |
Color: 0.04Lux(F2.0, 1/30sec)
BW: 0.004Lux(F2.0, 1.30sec), 0Lux(IR LED on) |
| Video Out |
USB: Micro USB Type B, 1280×720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.6mm fixed focal |
| Max. Aperture Ratio |
F2.0 |
| Angular Field of View |
H: 94.8˚ / V: 49.3˚ / D: 114.3˚ |
| Focus Control |
Fixed |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
±5° / 0°~67° / ±90° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR |
| Wide Dynamic Range |
150dB |
| Digital Noise Reduction |
SSNRV |
| Digital Image Stabilization |
Support |
| Defog |
Support |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, 4 point quadrangle zones
– Color: Grey/Green/Red/Blue/Black/White
– Mosaic |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker(2~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification |
| Alarm Triggers |
Analytics, Network disconnect |
| Alarm events |
When alarm trigger occurred
– File upload(image) : e-mail/FTP
– Notification : e-mail
– Recording : SD/SDHC/SDXC or NAS recording at event triggers
– Handover |
| Audio In |
Selectable(mic in/line in/built-in mic)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| IR Viewable Length |
15m(49.21ft) |
| Network |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SRTP, LLDP |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access Log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| General |
| Memory |
1024MB RAM, 256MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP66, IK10, NEMA4X
EN55011:2009+A1:2010, EN50581:2012,EN50121-3-2:2015, EN61000-4-2:2009, EN61000-4-3:2006+A2:2010, EN61000-4-4:2012, EN61000-4-5:2014, EN61000-4-6:2009, EN50155:2007 |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 6.70W |
| Mechanical |
| Color / Material |
Ivory / Aluminum |
| Product Dimensions / Weight |
98.9×52.0x100.0mm(3.89×2.05×3.94″), 295g(0.65 lb) |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
35.3m(115.85ft) |
| Observe (63PPM/ 19PPF) |
14.1m(46.34ft) |
| Recognize (125PPM/ 38PPF) |
7.1m(23.17ft) |
| Identify (250PPM/ 76PPF) |
3.5m(11.58ft) |
