AMG350-4GAT-1G-P120
AMG350-4GAT-1G-P120 – Image 2
AMG350-4GAT-1G-P120 – Image 3
AMG350-4GAT-1G-P120 – Image 4
,

AMG350-4GAT-1G-P120

Ajouter à la liste d’envies

Demander un devis
4 x 10/100/1000Base-T(x) RJ45 Ports with 802.3at 30W PoE, 1 x 10/100/1000Base-T(x) RJ45 Port, DIN Rail / Wall Mount, -40°C to +75°C, 48-56VDC Power Input
Key Features
  • Compact size – ideal for confined spaces, including camera poles and roadside cabinets
  • Innovative thermally efficient housing ensures high levels of device reliability under full load
  • -40°C to +75°C temperature maintains performance in extreme conditions
  • Plug & Play – no need for any user configuration
  • DIN rail mountable – quick to install and remove for maintenance
  • Dual redundant power inputs
  • Supports 15W and 30W PoE
  • Auto-Negotiation (802.3u) – automatically determines the best connection speed
  • Manufactured in the United Kingdom
UGS : 5060811141717 Catégories : ,
MTBF (Hours) 500000
Power Consumption (W) 3
Power Inputs 2
Power Interface 4 Pin Removable Terminal Block
Input 1 Voltage 48-56 VDC
Input 2 Voltage 48-56 VDC
Heat Dissipation at Max Load (BTU/h) 420
Total Number of Ports 5
Speed 1Gb
1Gb RJ45 Ports 5
PoE 30W PoE
30W PoE Ports 4
PSE Modes Mode A
RJ45 Port(s) Feature 2 kV Isolation Protection

Auto MDI/MDI-X
Ethernet Standards (Media Converters) IEEE 802.3i (10Base-T)

IEEE 802.3u (100Base-TX)

IEEE 802.3ab (1000Base-T)

IEEE 802.3x (Flow Control)

IEEE 802.3af (15W PoE)

IEEE 802.3at (30W PoE+)
Operating Temperature -40°C to +75°C
Storage Temperature -40°C to +85°C
Recommended PSUs AMGPSU-I48-P120 (120W 48VDC)

AMGPSU-I48-P240 (240W 48VDC)
IP Rating IP40
Product Class Industrial Grade
Warranty AMG Lifetime Warranty
Compliance NDAA Compliant

TAA Compliant
